SPARROW HD MWIR Detector

SPARROW-HD

Description
Performance
Configurations
Documents

The Sparrow-HD is a cutting-edge, low-SWaP 5μm MWIR detector module engineered to
meet the stringent demands of the defense wide distribution market. Its innovative design
ensures exceptional performance while minimizing size, weight and power consumption,
making it a game-changer in the industry.
Sparrow-HD is based on two mature sensing material technologies:

• XBn with 4.2μm cut-off, operating at 150K and enabling minimal power consumption
• Hot Full-Mid-Wave (HFM) with 4.85μm cut-off, operating at 120K and supporting up to 200Hz

Parameter
Performance
Detector format
1280 x 1024, 5µm
Technology
XBn / HFM
Cooler
Split linear cooler
Cold filter
3.6-4.15 μm / 3.6-4.85 μm
Operating temperature
150°K / 120°K
Cold shield
F/1.8, 12mm height
Integration modes
ITR, IWR
Gain options
0.9Me / 0.9Me / 2.6Me
Maximal frame rate
Up to 60Hz / Up to 200Hz
Video output
Camera-Link or MIPI CSI-2
Digital signal resolution
12/13 bit
Readout mode
Normal / 2×2 Binning / 4×4 Binning
Readout direction
Bottom-up / Left-Right
Windowing
Flexible: at 8 row steps
NETD
40mK at 70% of 0.9Me capacitor / 25mK at 70% of 2.6Me capacitor
Residual non-uniformity
< 0.05% STD/DR at 20-80% well fill
Power consumption @ 23°C
< 4W / < 6W at 60Hz, 0.9Me-
Size
< 70 x 53 x 58mm (Opt. Axis) / < 72 x 53 x 62mm (Opt. Axis)
Weight
< 350 Gr / < 380 Gr
Cooler reliability - MTTFF
> 22,000 hours For GM (Ground Mobile) @ 35°C
Integrated video processing key features (optional)
• Operates at 60Hz • Non Uniformity Correction (NUC) • Bad-Pixel Replacement (BPR) • Image Enhancement and Dynamic Range Compression (DRC) • Noise Reduction • Digital Zoom x2, x4 • Embedded User Interface and Overlay Graphics

CONFIGURATIONS
OPTIONS
Technology
XBn & HFM
Module configurations
Two module configurations - horizontal and vertical, with the FPA long axis either parallel or perpendicular to the module’s long axis
